How do I set up my P-DISC?

  • Updated

Whether you’re using the P-DISC for the first time or helping a family member get started, the setup of all our P-DISC is quick and easy.

Below you’ll find a simple guide for all our OOONO P-DISC. Just click on your device and get started:



P-DISC NO3

P-DISC NO3

P-DISC NO2

P-DISC NO2

P-DISC NO1

P-DISC NO1

P-DISC NO3


  1. To set up the P-DISC NO3 for the first time, hold the (O) button on the back of the device for about three seconds.

  2. The P-DISC NO3 emits a sound and the lights at the back briefly flash green, indicating that the device is now active and displaying the factory-set time. After ten seconds, you will hear another sound. The device is now displaying the parking time.

Important!

The time is displayed in 24-hour format and cannot be switched to the 12-hour AM/PM format.



P-DISC NO2


  1. The first time you set up the P-DISC NO2, you need to set the exact time and date for it to be able to set the parking time automatically.

  2. The P-DISC NO2 offers two buttons to navigate the settings menu. One to navigate the menus and one to confirm.

To set time and date, please follow these steps:

  1. Push and hold (O) for around 3 seconds until the numbers in the display starts flashing.
  2. Start out by setting hours. Use (</>) to adjust and click (O) to confirm.
  3. Then set the minutes. Use (</>) to adjust and click (O) to confirm.
  4. Move on to set the year. Use (</>) to adjust and click (O) to confirm.
  5. Next, set the month. Use (</>) to adjust and click (O) to confirm.
  6. Lastly, set the date. Use (</>) to adjust and click (O) to confirm.

When the above steps have been followed successfully, your P-DISC will emit a sound to confirm that it is set up correctly. Your P-DISC NO2 is now ready to use.

Important!

The time is displayed in 24-hour format and cannot be switched to the 12-hour AM/PM format.



P-DISC NO1

The OOONO P-DISC NO1 is able to set parking time automatically when you park your car. However, before it can do so, it needs to have the current time and date set correct.

Follow the steps provided below to set up the P-DISC NO1 correctly.

Turn on and set time

  1. Detach the parking disc from the clear plastic holder, it will automatically switch on, and numbers will appear in the display.
  2. Press and hold the (O) - button for a few seconds until the numbers start flashing.
  3. Set hours with the (</>) buttons and press the (O) button once to confirm. Set minutes in the same manner.
  4. Select “DST” to choose automatic adjustment between winter time and daylight saving time (factory setting is ON). If automatic adjustment is not preferred, then select “nDST” with the help of the [</>] buttons. Press the (O) button to continue and confirm.

PD1 2.jpg

Set date and parking interval

  1. If “DST” is on, set year, month, and date, with the help of the [</>] buttons. Press the (O) button to continue and confirm.
  2. The parking time interval is set to “0:15” (factory setting). You can set the interval to “0:30” or “0:00”, which is a 30 minute or 1 minute interval, with the help of the [</>] buttons. Press the (O) button to confirm and finish setup.
    You can read more about the parking interval here: How it works
Important!

The time is displayed in 24-hour format and cannot be switched to the 12-hour AM/PM format.
